IAG Fire-Lock 2.4L FA24 Head Gaskets (1 Pair W/ Fire-Lock Rings) For 14mm Head Studs Only

Our proprietary "Fire-Lock" Head gasket system has been proven in our record-setting EJ Powered race cars to be the strongest Subaru head gasket system ever produced. We’re excited to announce that this technology has now come to the Subaru FA24F engines found in the 22+ WRX. To achieve these results, our engineers isolated the combustion chamber sealing from the fluid sealing properties of the head gaskets. Tested beyond 1000 horsepower, these gaskets provide the durability and reliability needed for high-horsepower builds and extreme boost applications. The gaskets are manufactured from an asbestos-free composite raw material and feature silicone-based beading applied to critical areas to improve sealing around all water and oil passages. The separate gasket bodies take care of sealing oil and coolant passages, keeping them out of the combustion chamber. The combination of the alloy compression shims and gaskets assures maximum sealing for the Subaru 2.4L FA24 engine.

• Unique Fire-Lock Rings help contain extreme cylinder pressures. Cylinder liners must be machined to accept the fire-lock rings.

Vehicle Specific

• Subaru: WRX 22 - 24 Base / GT / Limited / Premium / RS / Sport / Sport-tech / TR

Attributes:

• Brand Name: IAG Performance
• GTIN: 00887753986221
• Color: Gray
• Configuration: Two Piece
• Cylinder Bore Diameter: 94.5
• Gasket Sealant Included: No
• Grade Type: Performance
• Material: Composite
• O-Ring Material: Alloy
• Thickness: 0.051

Extended Information:

• Country of Origin: United States
• Emissions : Emissions Compliance Exempt
• Life Cycle Status: Released

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 13 x 8.5 x 0.5 inches
• Weight: 0.7 POUNDS
