IAG Performance Oil Pickup For 2013-20 Subaru BRZ / FR-S / 86 FA20D

Oil pickups are a common failure point in the FA20D, BRZ, FRS and GT86 engines, especially when pushing your Subaru to its limits. The factory pickup can lead to severe engine damage or catastrophic failure due to the screen dislodging under high oil pressure, allowing debris and even fragments of the screen itself to enter the engine. Subaru’s design is also notorious for restricting oil flow, potentially causing oil starvation. The IAG Performance Oil Pickup for the 2012-2020 FA20D BRZ / FRS / GT86 is designed to solve these issues. With an enhanced design that improves oil flow and durability, it offers a dependable solution to the common problems associated with OEM oil pickups. IAG’s Oil Pickup will keep your engine performing at its best, no matter how hard you drive. The OEM strainer screens are the weak link in the Subaru factory pickups. The factory tack-welds that hold the screen in place block part of the screen, obstructing oil flow, while the heat from sloppy welding on the screen’s surface causes it to become brittle and prone to breakage. IAG Performance’s Oil Pickup design addresses these issues by incorporating the use of a robust mesh screen that is pressure fitted between a 2-piece housing cast from premium quality 304 stainless steel. The screen is held securely in place by the housing, which is hand TIG welded with care to prevent overheating or causing obstructions on the screen’s surface. Notably, there is no welding done to the screen itself, protecting it from damage and ensuring that it flows freely. Additionally, we've eliminated the retaining ring, which increases the surface area by nearly 32% over the OEM version. Whether your FA20D, BRZ, FRS or GT86 engine is modified or not, the IAG Oil Pickup is built to stand strong against the pressure of the most demanding driving conditions.

• Enhances oil flow efficiency in your FA20D engine.
• No welds or retaining ring means a free-flowing surface area that is nearly 32% over the OEM version.

Vehicle Specific

• Scion: FR-S 2013 - 2016 Subaru: BRZ 2013 - 2020 Toyota: 86 2017 - 2020

Attributes:

• Brand Name: IAG Performance
• GTIN: 00887753843746
• Bracket Material: Stainless Steel
• Gasket Or Seal Included: Yes
• Mounting Bracket Included: Yes
• Mounting Hole Quantity: 2
• O-Ring Material: Viton
• Tube Length: 4
• Tubing Material: Stainless Steel

Extended Information:

• Country of Origin: US
• Emissions : Emissions Compliance Exempt
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 10.5 x 3.5 x 3.5 inches
• Weight: 1 POUNDS
